Quick Details

  • Type: Laminating Machine
  • Condition: New
  • Application: Beverage, Food
  • Packaging Type: Film
  • Packaging Material: Paper, plastic
  • Automatic Grade: Automatic
  • Driven Type: Electric
  • Voltage: 380V
  • Power: 52kw
  • Place of Origin: Zhejiang, China
  • Brand Name: Allfine
  • Model Number: LCBF-1000
  • Dimension(L*W*H): 9600(L)*2850(W)*3300(H)
  • Weight: approx. 8900kg
  • Certification: CE ISO9001
  • After-sales Service Provided: Engineers available to service machinery overseas

Packaging & Delivery

Packaging Details export standard package
Port ningbo

LCBF-1000 series 70m/m Dry Laminating Machine BOPP,PET,CPP, Aluminum foil, and paper, 2-layer repetitious laminating


Note:Electric source: three-phase switch by air 380V 60Hz


Usage characteristic
This machine is suitable for reel-shape materials, such as BOPP,PET,CPP, Aluminum foil, and paper, 2-layer repetitious laminating, high strength production, producing high-quality compound materials with high freshness preserving, and boiling & steaming resistance.


1. Frequency conversing synchronic timing is adopted for main machine, making more stable operation.
2. Two means of glue applying, cobwebbing roll sizing and rubber roll gluing .
3. Top air style oven open, initiative guiding roll in oven .
4. 4-sect heating in drying tunnel, possible to control temperature by segments .
5. Photoelectric error correction for the first unreeling.
6. Reeling and unreeling by tumbling dual-station mechanism, realizing auto material change without machine halt.
7. Oil worming system for composite reel, constant temperature control.


Technical data
Laminating stratification2pcs/each
General printing base materialBOPP,PET,PE etc. compound material
Max width of base material1000mm
Max speed100m/min
Max laminating speed70m/min
Diameter of glue applying, cobwebby roller150mm
Width of quid roller1030mm
Width of inner body1240mm
Diameter of rewinding and winding750mm
Main drive motor5.5kw alternative current frequency motor (frequency converter 2pcs)
Weightapprox. 8900kg
Overall dimensions9600(L)×2850(W)×3300(H)
Machine coloroffwhite (you can choose any other colors)


1Ink scrapermmPiece
2Ringent wrench12×14Piece1
3Ringent wrench17×19Piece1
4Plum blossom wrench14×17Piece1
5Screwdriver Piece1
6Inner hexagonal wrench Piece1
7Press rubber roller1000mmPiece1
8Gluing roller1000mmPiece1
9Air compressor Set1


Video:info me for the mp4

For more information, please add my whatapp/viber/mobile/wechat/qq:+8615158408090

Q:1.How can I get the trainning and machine installation after I order it?
A)Machine manual and operation video will be offered
B)Professional engineers team can offer 7-24 service( we will reply your questions within 24 hours)
C)Oversea service is available
D)Welcome to visit our factory for the trainning
Q:2.Do you arrange shipment for the machine?
A)Under CFR or CIF terms, we are responsible for shipping from China port to the destination port.
B)Under FOB or EXW terms, clients shall arrange shipment by themselves or their agent
Q:3.How is the package?
A)water proof plastic film package
B)Fumigation wooden box
Q:4.Are you manufacture or trading company?
A)manufacturing and trading combo
B)we are the group company with many sub factorys
Q:5.Where is your factory located? How can i visit here?
A)Our office is daohang road,dongshan economical development zone,ruian city,wenzhou city,zhejiang province
B)Our airport is Wenzhou Longwan International Airport .It is about 40 minutes from airport to our factory
Q:6.Can you do OEM?
No problem
Q:7.How can I get some samples?
we can make samples as your detailed requirements or own design.you can arrange RPI(remote pick up)service upon Fedex,Ups,Dhl,Tnt ect to have the samples collected or info us your dhl consignee acount no
Q:8.I never use this kind of machine before, is it easy to learn?
User friendly english manual and operation video will be offered, if there is still any questions, we can talk by whatapp,skype,viber ect online service.Moreover, you can come to our factory to learn how to use it before shippment, our technician will get you professional guidance.we can also offer the oversea service.
Q:9.How can I know this machine is suitable for me?
before ordering, we will offer every details of the machinery for your reference, or you could tell us your detailed requiements, our technician will recommend the most suitable machine for you. furthermore. we can make a sample advance for you to check if you give us your drawing

Agents wanted all around the world
Agents Introduction:
We are sincerely seeking companies around the world to represent us and distribute our products in their market. Exclusive agencies are allocated within each country.
Products Introduction
Gravure printing machine, Lamination machine, Slitting machine , Flexo printing machine, Bag making machine, Film blowing machine, screen printing machine, inspection and rewinding machine etc.
Agent Requirements
Agents must have:
1) A good reputation and sale volume in their country.
2) Annual sales turnovers of more than USD200,000.
3) Search for long-term and stable partnership.
Agents Required for the Following Countries:
Europe, Middle East, Africa, Asia, Latin America etc. All over the world
If you are interested in becoming an agent please be free to contact me:mob/whatapp/viber:+8615158408090
Our Advantage:

1. O2O- online to offline connection development mode

2. Agent all around the world to market the machine.

3. 30% profit to invest into new tech and research

4. Oversea showroom to catch more clients and help agent to less the cost

5. Manufacturing and trading combo


Machine pictures:
Finished products pictures:
